Powder Metallurgy and Powder Characterization

Contact:  Dr. Konrad Kosiba, Prof. Julia Hufenbach

  • Suitable for the batch-type ultra-fine grinding and alloying (dry and wet) of medium-hard, hard-brittle and hard-tough materials, as well as soft and fibrous materials
  • Number of grinding bowls: 4
  • Volume of grinding bowls: 50 to 500 ml
  • Milling speed: 60 to 400 rpm
A Retsch planetary ball mill with its cover open, showing three cylindrical stainless steel grinding jars arranged on a circular platform. Each jar is wrapped in a slotted metal cage with rectangular cutouts. The components are silver-gray against a dark chamber interior.
  • Suitable for pressure-assisted sintering
  • Setups for hot pressing and extrusion available
  • Atmosphere: vacuum or inert gas
  • Maximum load: 350 kN
  • Maximum temperature: 973 K
  • Temperature control: Pt/PtRh thermocouple
  • Monitor of processing parameters: load, temperature, shrinkage
Two linked images of a hot press. On the left, a photograph of the press with its die assembly circled in red. On the right, a labeled diagram of the vacuum chamber's internal components, stacked top to bottom: thermocouple, rams, die supports, punches, and a central induction coil surrounding the die. Dashed red lines connect the diagram labels to the corresponding parts in the photograph.
  • Dynamic picture analysis of powders and loose bulk solids (granules, fibers)
  • Robust and reliable device for precise and quick measurements (several thousand to millions of particles)
  • Particle size analysis from 1 µm to several millimeters
  • Detailed 2D-analysis of shape characteristics (anisotropy, sphericity, symmetry)
Powder analyzer Camsizer X2 by Retsch with X-DRY module in a laboratory setting.
  • Automated powder flowability measurement device based on a rotating drum principle
  • Dynamic measurement principle with adjustable rotating speeds for the detection of the air/powder interface relations
  • Characterization of flowing angle and cohesive index
  • Reduction cell for the analysis of small powder volumes

Image: Powder flow analyzer: GranuDrum _ EN

Compact rectangular GranuDrum powder flow analyzer with a window and handle on a table next to a monitor displaying software.

Selected features:

  • Compact ultrasonic atomizer for a wide range of metal alloys including Ti-based or other reactive metal materials
  • Highly spherical metal powders suitable for material development in the field of additive manufacturing (powder bed fusion, deposition welding)
  • Flexible machine setup for the atomization of wire or bulk (rods, several millimeters diameter)
  • Low operating costs and high efficiency
Metal powder atomization system ATO Lab Plus consisting of a white rectangular main unit with a black front door and a blue cubic auxiliary unit with cables in a laboratory room.
View through a round observation window into a green-lit chamber with metallic components and connected hoses and valves.
